PT100 RESISTANCE THERMOMETER OF GLASS, (N16B) Assembly: WT-GL-3/6-303-300-2000

PT100 RESISTANCE THERMOMETER OF GLASS (N16B)Assembly: WT-GL-303-3/6-300-2000General Specifications:Labor resistance thermometer of glass Pt100, acc. to DIN EN 60751 Class A, 4-wire connection, with glass shaft ø 6 mm, narrowed at sensor to ø 3 mm, compensating line fix connected through transition casing made of stainless steel, teflon/silicone insulated, cable length: 2 m, cable outlet secured by means of heat-shrink tubing.Glass shaft Ø: 3/6 mmNominal length: 300 mmRange of application: -50 °C to +250 °CConnection via plug PHYSICS resolution 0.01 °CSuitable to PHYSICS 100 and 300 more
